Interface
USB
IP

IPS3102

  • 1/3" CMOS

  • Full HD - 1920 x 1080 Pixels

  • 10X Optical Zoom
  • Resolution (H x V pixels) 1920 x 1080 Pixels
    Image Sensor 1/3" CMOS
    Scanning System Progressive Scan
    IR cut filter Colour (Day), Monochrome (Night), Auto, Schedule
    Shutter Time 1/30(25) - 1/10.000
    Zoom Ratio 10X Optical Zoom
    Lens/Focal length 4.9-49mm
    Angle of View
    • 57.23°-6.25°(H)
    • 34.07° - 3.51°(V)
    Video Compression H.264, Motion JPEG
    Frame Rate
    • H.264 : up to 30 FPS @ 1920 x 1080
    • MJPEG : up to 30 FPS @ 720 x 480
    Video Streaming RTP/HTTP, RTP/TCP, RTP/UDP, Multicast
    Video Bitrate 128Kbps – 5Mbps
    Auto Gain Control 0 ~ 42dB
    Sense Up Off / Auto(x30)
    3D Noise Reduction Off / On (2D, 3D)
    Privacy Masking Off / On (8 independent areas)
    ePTZ & Digital Zoom 64X
    Alarm Function
    • Image upload over FTP and E-mail by alarm / Motion Detection
    Network Interface 10Mbps / 100Mbps, RJ-45
    Audio 2-way Audio, G.711
    SD Card/ SD card recording Support Micro SD/SDHC card
    Dimensions 164 x 135mm
    Weight 1150g
    Power Supply DC12V-11.5W / PoE-13W
