Interface
USB
IP

MD2222

  • 1/2.7" CMOS

  • 1920 x 1080 Pixels

  • Full HD
  • Resolution (H x V) 1920 x 1080 Pixels
    Image Sensor 1/2.7" CMOS
    Scanning System Progressive Scan
    IR cut filter Colour (Day), Monochrome (Night), Auto, Schedule
    Shutter Time 1/30(1/25)s - 1/30.000s
    Lens/Focal length 3.6mm
    Angle of View
    • 96° (H)
    • 51° (V)
    • 115° (D)
    Video Compression H.264, Motion JPEG
    Frame Rate
    • H.264 : up to 30 FPS @ 1920 x 1080
    • Motion JPEG : up to 30 FPS @ 1920 x 1080
    Video Streaming RTP/HTTP, RTP/TCP, RTP/UDP, Multicast
    Video Bitrate 128Kbps - 12Mbps
    Sense Up Off / 1 Frame / 2 Frames
    Sense Up+ Yes
    Auto Gain Control 42 dB Variable Gain
    3D Noise Reduction Off / 1 – 32 Selectable
    2D WDR Off / Auto / x2 / x3 / x4
    Privacy Masking Off / On (4 independent areas)
    ePTZ & Digital Zoom Yes
    Alarm Function
    • Motion/Tamper/Audio/Network lost detection
    Network Interface 10 Base-T / 100 Base-TX, RJ-45
    Audio One-way Audio, G.711 / PCM (Built-in microphone)
    SD Card Support Micro SD/SDHC/SDXC card
    Dimensions Ø105 x 39mm
    Weight 250g
    Power Supply DC12V-3.2W / PoE-4.4W
