| Resolution (H x V pixels) |
1920 x 1080 Pixels |
| Image Sensor |
1/2.8" CMOS |
| Scanning System |
Progressive Scan |
| IR cut filter |
Colour (Day), Monochrome (Night), Auto |
| Shutter Time |
Auto / Manual (1/1 - 1/10.000) |
| Zoom Ratio |
30X Optical Zoom |
| Lens/Focal length |
4.3mm (Wide) - 129mm (Tele) |
| Angle of View |
- 64.45°- 2.41°(H)
- 39.27° - 1.36°(V)
|
| Video Compression |
H.264, Motion JPEG |
| Frame
Rate |
- H.264 : up to 60 FPS @ 1920 x 1080
- Motion JPEG : up to 30 FPS @ 720 x 480
|
| Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video Bitrate |
128Kbps – 12Mbps |
| Auto Gain Control |
0-30 dB |
| 3D Noise Reduction |
Off / On (2D, 3D) |
| 2D WDR |
Yes |
| Privacy Masking |
Off / On (16 independent areas) |
| ePTZ & Digital Zoom |
16X |
| Alarm Function |
- Alarm / Motion / Audio Detection triggering recording into SD card
- Image upload over HTTP, FTP and E-mail by audio / Motion Detection
|
| Network Interface |
10/100/1000Mbps Base-T, RJ-45 |
| Audio |
2-way Audio, G.711 / PCM |
| SD Card/ SD card recording |
Support Micro SD/SDHC/SDXC card |
| IP Rating |
IP66 |
| IK Rating |
IK10 |
| Dimensions |
Ø275 x 192mm |
| Weight |
2750g |
| Power Supply |
AC24V / DC24V / PoE |
