Resolution (H x V) |
1920 x 1080 Pixels |
Image Sensor |
1/2.8" CMOS |
Scanning System |
Progressive Scan |
IR cut filter |
Colour (Day), Monochrome (Night), Auto, Schedule |
Shutter Time |
1/30(1/25)s - 1/8.000s |
Lens |
2.8-12mm |
Angle of View |
- 91.2° - 25.5°(H)
- 68.4° - 19.1°(V)
- 114° - 31.9°(D)
|
IR Radiant Distance |
45M |
Infrared LED Angle |
30° |
Peak wavelength |
850nm |
Video Compression |
H.264, Motion JPEG |
Frame
Rate |
- H.264 : up to 30 FPS @ 1920 x 1080
- MJPEG : up to 15 FPS @ 1920 x 1080
|
Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
Video Bitrate |
128Kbps - 8Mbps |
Sense Up |
Off / 1 Frame / 2 Frames / 3 Frames / 7 Frames |
Sense Up+ |
Yes |
Auto Gain Control |
36 dB Variable Gain |
3D Noise Reduction |
Off / 1 – 32 Selectable |
2D WDR |
Off / Auto / x2 / x3 / x4 |
Privacy Masking |
Off / On (4 independent areas) |
ePTZ & Digital Zoom |
Yes, ROI is supported |
Alarm Function |
- Face / Tampering / Audio / Motion / Alarm detection
|
Network Interface |
10Mbps / 100Mbps Base-T, RJ-45 |
Audio |
2-way audio , G.711 / PCM |
SD Card |
Support Micro SD/SDHC card |
IP Rating |
IP66 |
Dimensions(W x H x D)mm |
121.5 x 109 x 231mm, Bracket : 160mm (L) |
Weight |
1700g |
Power Supply |
AC24V-15W / PoE-17W |
