| Resolution (H x V pixels) |
1920 x 1080 Pixels |
| Image Sensor |
1/2.7" CMOS |
| Scanning System |
Progressive Scan |
| Shutter Time |
1/30s - 1/8.000s |
| Lens |
2.8mm |
| Angle of View |
|
| Video Compression |
H.264, Motion JPEG |
| Frame
Rate |
- H.264 : up to 30 FPS @ 1920 x 1080
- MJPEG : up to 15 FPS @ 1920 x 1080
|
| Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video Bitrate |
128Kbps – 8Mbps |
| Sense Up |
Off / 1 Frame / 2 Frames / 3 Frames / 7 Frames |
| Sense Up+ |
Yes |
| Auto Gain Control |
36 dB Variable Gain |
| 3D Noise Reduction |
Off / 1 – 32 Selectable |
| 2D WDR |
Off / Auto / x2 / x3 / x4 |
| Privacy Masking |
Off / On (4 zones) |
| ePTZ & Digital Zoom |
Yes, ROI is supported |
| Alarm Function |
- Face / Tampering / Audio / Motion Detection
- Image upload over FTP and E-mail by face / Tampering / Audio / Motion Detection
|
| Network Interface |
10Mbps / 100Mbps Base-T, RJ-45 |
| Audio |
1-way Audio, G.711 / PCM |
| SD Card |
Support Micro SD/SDHC card |
| Dimensions |
Ø105 x 39mm |
| Weight |
250g |
| Power Supply |
DC12V-4.5W / PoE-5W |
